Industrial Dehumidifier

    Applicable Scenarios: villas, hotels, swimming pools, large warehouses, equipment rooms (server facilities), pharmaceutical factories, and workshops.


Industrial Dehumidifier Structural Features

1. Forward-Curved Centrifugal Fan: High Airflow, Low Noise
The unit uses a forward-curved centrifugal fan, which delivers low noise and high air volume while offering a longer service life.
2. Sheet-Metal Body: Sturdy and Durable
The entire unit adopts a sheet-metal frame structure—robust and durable with no deformation, and highly resistant to corrosion and oxidation for an exceptionally long service life.
3. Smart Display: Simpler Operation
The intelligent LCD display accurately indicates the dehumidification status, keeping all information clearly visible at a glance, while virtual function buttons make operation even simpler.

Specifications and Parameters

Model LTCF-75(suspended) LTCF-10S(suspended) LTCF-125(suspended) LTCF-225(suspended) LTCF-305(suspended) LTCF-405(suspended)
Power Supply 380V/50Hz 380V/50Hz 380V/50Hz 380V/50Hz 380V/50Hz 380V/50Hz
Dehumidification Capacity 7kg/h 10kg/h 12kg/h 20kg/h 30kg/h 40kg/h
Condition 30℃ RH80% 30℃ RH80% 30℃ RH80% 30℃ RH80% 30℃ RH80% 30℃ RH80%
Maximum Power 2800W 4250W 4650W 8400W 12000W 15000W
Maximum Current 5.5A 6.5A 7.5A 13A 18A 23A
Airflow 1800m³/h 2500m³ /h 3000m³ /h 5600m³/h 7400m³/h 0000m³h
External Static Pressure 100Pa 100Pa 120Pa 150Pa 200Pa 200Pa
Filter Primary G4 Primary G4 Primary G4 Primary G4 Primary G4 Primary G4
Applicable Temperature 5-38℃ 5-38℃ 5-38℃ 5-38℃ 5-38℃ 5-38℃
Noise ≤65DB(A) ≤65DB(A) ≤65DB(A) ≤75DB(A) ≤75DB(A) ≤75DB(A)
Return Air Port 540*430mm 540*430mm 604*554mm 1004*524mm 1234*654mm 1234*654mm
Supply Air Port 540*430mm 540*430mm 604*554mm 1004*524mm 1234*654mm 1234*654mm
Unit Dimensions 1050*700*700mm 1050*700*700mm 1100*900*700mm 1100*900*700mm 1510*1500*800mm 1510*1500*800mm
